Cantilever Lumber Rack
Arms on 2x4 uprights fastened into the studs, so boards and offcuts lie flat off the floor. Each arm is a 2x4 block between two plywood triangles that straddle the upright.
Standard size100 15/16 × 15 × 72 in
You'll need6 2x4s (8 ft), 2 sheets of 3/4" plywood
Parts to cut52
Plan$12, once
Change any size and Benchside redraws it, recounts the material and rebuilds the plan.
Built around your shop
- 16" or 24" studs, with an upright on every stud or every other one
- As many uprights and arms as your wall takes
- How long the uprights are and how high they start
- How deep and tall the arms are
How it goes together
- Cut the plywood sides on the diagonal: one rectangle makes two.
- Screw each arm together: a block laid flat between two sides, flush at the top and front.
- Fasten each upright flat to a stud, plumb.
- Slide the arms over the uprights, level with their neighbors, and screw them on.
The plan has every step written against the part letters in its cut list, with drawings of each part that has joinery.
What you can change
SizeArmsUprights and arm blocksArm sides
In the $12 plan
- Cut list with every part lettered
- Cutting diagrams for every sheet and board, grain kept straight
- Printable build plan: overview, drawings, part drawings and steps
- CNC files: DXF sheets and a STEP 3D model
Bought once for your design, and it stays yours through any edits and resizes. The 3D view and shopping list are free.
